IDEAL 7
Specifications
| Engine | ||
|---|---|---|
| Engine Power | 310kW (416hp) 416hp 310kW | |
| Rated Engine Speed | 1900r/min | |
| Make | AGPWR 9.8L Tier 4F 7- Cylinder | |
| Displacement | 160cm^3 (9.8cu. in.) 9.8cu. in. 160cm^3 | |
| Number of Cylinders | 7 | |
| Fuel Type | Diesel | |
| Fuel Injection | Direct Injection | |
| Fuel Tank Capacity | 330gal. (1,250.0L) 1,250.0L 330gal. | |
| DEF Tank Capacity | 47gal. (180.0L) 180.0L 47gal. | |
| Warming | Block Heater | |
| Transmission | ||
|---|---|---|
| Maximum Speed | 24mph (40km/h) 40km/h 24mph | |
| Type | Hydrostatic | |
| Ranges | 2 | |
| Speed Control | Cruise | |
| Drive | 2WD, 4WD | |
| Differential | Locking | |
| Additional Drivetrain | ||
|---|---|---|
| Steering Mode | rear wheel steer | |
| Hydraulics | ||
|---|---|---|
| System Capacity | 29gal. (110.0L) 110.0L 29gal. | |
| Maximum Available Hydraulic Oil | 21gal. (80.0L) 80.0L 21gal. | |
| Steering | Hydraulic Power | |
| Technology | ||
|---|---|---|
| Telemetry | 5 Year Fendt Connect Subscription | |
| Electrical | ||
|---|---|---|
| Alternator | 320A | |
| Battery | 1000CCA | |
| Operator Station | ||
|---|---|---|
| Configuration | Cab | |
| Feeding System | ||
|---|---|---|
| Feeder House Lifting Capacity | 9997lb. (4535kg) 4535kg 9997lb. | |
| Lift Cylinder Diameter | 3-3/8" (85mm) 85mm 3-3/8" | |
| Feeder Housing Chains | 3 | |
| Reverse | Electro Hydraulic | |
| Feeder Width | 3225cm (1") 1" 3225cm | |
| Rock Trap | Right Hand | |
| Threshing | ||
|---|---|---|
| Separator Type | Single Rotor | |
| Class | 7 | |
| Rotor Length | 15' 10-7/16" (4837mm) 4837mm 15' 10-7/16" | |
| Rotor Diameter | 1' 11-5/8" (600mm) 600mm 1' 11-5/8" | |
| Maximum Rotor Speed | 920r/min | |
| Threshing Area | 8.9sq. ft. (0.83m^2) 0.83m^2 8.9sq. ft. | |
| Separation Area | 15.5sq. ft. (1.44m^2) 1.44m^2 15.5sq. ft. | |
| Total Separation Area | 24.4sq. ft. (2.27m^2) 2.27m^2 24.4sq. ft. | |
| Cleaning | ||
|---|---|---|
| Chaffer Area | 29.2sq. ft. (2.71m^2) 2.71m^2 29.2sq. ft. | |
| Sieve Area | 52.7sq. ft. (4.90m^2) 4.90m^2 52.7sq. ft. | |
| Total Cleaning Area | 80.2sq. ft. (7.45m^2) 7.45m^2 80.2sq. ft. | |
| Sieve Adjustment | Electric | |
| Maximum Cleaning Fan Speed | 1400r/min | |
| Return System | Separate | |
| Grain Handling | ||
|---|---|---|
| Unloading Rate | 4bu. per second, 6bu. per second | |
| Grain Tank | 350bu., 485bu. | |
| Unloading Auger Length | 30' 1/4" (9150mm) 9150mm 30' 1/4" | |
| Residue Management | ||
|---|---|---|
| Straw Chopper Knives | 56 | |
| Maximum Chopper Speed | 3600r/min | |
| Chaff Spreader | Hydraulic | |
| Wheels | ||
|---|---|---|
| Front | FD TrakRide 26 | |
| Track Width | 66cm (2' 2") 2' 2" 66cm | |
| Tensioning | Terminal Display | |
| Front Idler | Belt Tensioning Cylinder | |
| Boggie Wheels | 2 | |
| Rear Idler | Suspension Cylinder | |
| Footprint Length | 193cm (6' 4-3/16") 6' 4-3/16" 193cm | |
| Footprint Area | 2.55m^2 (27.4sq. ft.) 27.4sq. ft. 2.55m^2 | FD TrakRide 30 |
| Track Width | 76cm (2' 6") 2' 6" 76cm | |
| Tensioning | Terminal Display | |
| Front Idler | Belt Tensioning Cylinder | |
| Boggie Wheels | 2 | |
| Rear Idler | Suspension Cylinder | |
| Footprint Length | 193cm (6' 4-3/16") 6' 4-3/16" 193cm | |
| Footprint Area | 2.94m^2 (31.6sq. ft.) 31.6sq. ft. 2.94m^2 | FD TrakRide 36 |
| Track Width | 91cm (3') 3' 91cm | |
| Tensioning | Terminal Display | |
| Front Idler | Belt Tensioning Cylinder | |
| Boggie Wheels | 2 | |
| Rear Idler | Suspension Cylinder | |
| Footprint Length | 193cm (6' 4-3/16") 6' 4-3/16" 193cm | |
| Footprint Area | 3.52m^2 (37.9sq. ft.) 37.9sq. ft. 3.52m^2 | |
| Dimensions | ||
|---|---|---|
| Length | 38' 5-7/16" (11720mm) 11720mm 38' 5-7/16" | |
| Wheelbase | 13' 4-7/16" (4075mm) 4075mm 13' 4-7/16" | |
| Width | 16' 9-3/16" (5110mm) 5110mm 16' 9-3/16" | |
| Height | 13' 1-1/2" (4000mm) 4000mm 13' 1-1/2" | |
| Turning Radius | 15' 9" (4800mm) 4800mm 15' 9" | |
| Cab Width | 5' 3" (1600mm) 1600mm 5' 3" | |
