| Engine | ||
|---|---|---|
| Engine Power | 26.99kW (36.20hp) | |
| PTO Power | Dependent on: Transmission/Type/Syncro Shift, Dependent on: Transmission/Type/Hydrostatic | |
| Rated Engine Speed | 2,600r/min | |
| Make | ISEKI E3FH | |
| Displacement | 0.48gal. (1.83L) | |
| Number of Cylinders | 3 | |
| Fuel Type | Diesel | |
| Fuel Injection | Direct Injection | |
| Cooling | Liquid Cooled | |
| Transmission | ||
|---|---|---|
| Type | Syncro Shift(Optional), Hydrostatic(Optional) | |
| Reverser | Dependent on: Transmission/Type/Syncro Shift | |
| Ranges | 3 | |
| Gears Per Range | Dependent on: Transmission/Type/Syncro Shift | |
| Forward Speeds | Dependent on: Transmission/Type/Syncro Shift | |
| Reverse Speeds | Dependent on: Transmission/Type/Syncro Shift | |
| Speed Control | Dependent on: Transmission/Type/Hydrostatic | |
| Drive | 4WD | |
| Differential | Locking | |
| Technology | ||
|---|---|---|
| Entertainment | Dependent on: Operator Station/Configuration/Cab(Optional) | |
| Additional Drivetrain | ||
|---|---|---|
| Brakes | Wet Disc | |
| Steering Mode | front wheel steer | |
| Hydraulics | ||
|---|---|---|
| Pump | MF 1M B | |
| Pump Type | Gear | |
| Maximum Flow | 12.63GPM (47.80L/min) | |
| Rear Remote Valves | 1, 2(Optional), 3(Optional) | |
| Steering | Hydraulic Power | |
| Hitching | ||
|---|---|---|
| Rear Hitch | MF 1M B | |
| Hitch Category | Category 1 | |
| Lift Capacity 24" Behind Pins | 2,535.32lb. (1,150kg) | |
| Comfort | Draft Control(Optional) | |
| PTO | ||
|---|---|---|
| Middle Speed | 2000(Optional) | |
| Rear Speed | 540 | |
| Wheels | ||
|---|---|---|
| Front | GALXY Agri Trac 8-16(Optional) | |
| Size | 8-16 | |
| Ply | 6PR | |
| Tread Pattern | R1 (Ag) | |
| Tread Thickness | 1-1/4" (31mm) | |
| Weight | 15.88kg (35lb.) | |
| Rear | GALXY Agri Trac 13.6-28(Optional) | |
| Size | 13.6-28 | |
| Ply | 6PR | |
| Tread Pattern | R1 (Ag) | |
| Section Width | 35.56cm (1' 2") | |
| Overall Diameter | 129.54cm (4' 3") | |
| Static Loaded Radius | 59.69cm (1' 11-1/2") | |
| Weight | 54.43kg (120lb.) | |
| Operator Station | ||
|---|---|---|
| Configuration | Cab(Optional), Open ROPS(Optional), Dependent on: Operator Station/Configuration/Cab | |
| Access | Dependent on: Operator Station/Configuration/Cab, Dependent on: Operator Station/Configuration/Cab, Dependent on: Operator Station/Configuration/Cab | |
| Climate | Dependent on: Operator Station/Configuration/Cab, Dependent on: Operator Station/Configuration/Cab | |
| Steering Column | Tilting | |
| Steering Controls | Steering Wheel | |
| Throttle | Foot Pedal | |
| Wiper | Dependent on: Operator Station/Configuration/Cab, Dependent on: Operator Station/Configuration/Cab | |
| Electrical | ||
|---|---|---|
| Front Lights | Dependent on: Operator Station/Configuration/Cab, Dependent on: Operator Station/Configuration/Open ROPS | |
| Rear Lights | Dependent on: Operator Station/Configuration/Cab | |
| Voltage | 12V | |
| Battery Count | 1 | |
| Dimensions | ||
|---|---|---|
| Height | Dependent on: Operator Station/Configuration/Open ROPS, Dependent on: Operator Station/Configuration/Cab | |
| Weight | Dependent on: Operator Station/Configuration/Open ROPS, Dependent on: Operator Station/Configuration/Cab | |
| Loader | ||
|---|---|---|
| Loader | MF FL.2611(Optional) | |
| Lift Capacity | 625.96kg (1,380lb.) | |
| Maximum Lift Height – Pivot Pin | 254cm (8' 4") | |
| Lift Capacity to Max Height – Pivot Pin | 848.22kg (1,870lb.) | |
| Breakout Force – Pivot Pin | 1,338.10kg (2,950lb.) | |
| Max Rollback Angle | 42deg | |
| Max Dump Angle | 55deg | |
| Lift Cylinder Diameter | 5.99cm (2-3/8") | |
| Bucket Cylinder Diameter | 5.99cm (2-3/8") | |
| 3rd Function | Diverter Valve(Optional) | |
| Comfort | Suspension(Optional) | |
| Tool Carrier | Skid Steer Quick Attach | |
| Lift Path | Radial | |
