Description
Specifications
HP Rating @ 540RPM: 16HP,
Italian Series: AB1/A1.
Alternative to
S.26366, S.162392
Barcode 128
S.128674
Barcode EAN13
5045161286745
Brand
GARDLOC
Grease Coupler
Central Grease Nipple
Guard Type
Gardloc
HP Rating @ 540RPM
16
HP Rating @ 1000RPM
24
HP Rating Range @ 540RPM
up to 54
Implement End
1 3/8” x 6 Spline Q.R.
Italian Series
AB1/A1
Kilowatt Power Rating @ 540RPM
12
Kilowatt Power Rating @ 1000RPM
18
Lz Length (mm)
1010
PTO Series
AB1/A1
Related products
S.166692
Replacement Guard
S.163811
Tariff Code
8483908990
Torque (Nm)
210
Torque Range (Nm)
210-334Nm
Total Closed Length (mm)
1193
Tractor End
1 3/8” x 6 Spline Q.R.
Tube Profile
Triangle
Tube Ref
12502/12503
Universal Joint Dimensions
22 x 54mm
