Engine | ||
---|---|---|
Engine Power | 36.39kW (48.8hp) 48.8hp 36.39kW | |
PTO Power | 28.41kW (38.1hp) 38.1hp 28.41kW, 26.99kW (36.2hp) 36.2hp 26.99kW | |
Rated Engine Speed | 2600r/min | |
Make | ISEKI E4FH | |
Displacement | 148.29cu. in. (2.43L) 2.43L 148.29cu. in. | |
Number of Cylinders | 4 | |
Fuel Type | Diesel | |
Fuel Injection | Direct Injection | |
Cooling | Liquid Cooled |
Transmission | ||
---|---|---|
Type | Syncro Shift, Hydrostatic | |
Reverser | Power Shuttle | |
Ranges | 3 | |
Gears Per Range | 4 | |
Forward Speeds | 12 | |
Reverse Speeds | 12 | |
Speed Control | Cruise | |
Drive | 4WD | |
Differential | Locking |
Additional Drivetrain | ||
---|---|---|
Brakes | Wet Disc | |
Steering Mode | front wheel steer |
Hydraulics | ||
---|---|---|
Pump | MF 2M A | |
Pump Type | Gear | |
Hydraulic Flow | 12.63GPM (47.8L/min) 47.8L/min 12.63GPM | |
Rear Remote Valves | 1, 2, 3 | |
Steering | Hydraulic Power |
Hitching | ||
---|---|---|
Rear Hitch | MF 2M A | |
Hitch Category | Category 1, Category 2 | |
Lift Capacity 24" Behind Pins | 3086.47lb. (1400kg) 1400kg 3086.47lb. |
PTO | ||
---|---|---|
Middle | 2000 | |
Rear | 540 |
Technology | ||
---|---|---|
Entertainment | Radio |
Electrical | ||
---|---|---|
Front Lights | 6, 4 | |
Rear Lights | 2 | |
Worklight Type | LED | |
Voltage | 12V | |
Battery Count | 1 |
Operator Station | ||
---|---|---|
Configuration | Cab, Open ROPS, Side Windows | |
Access | Left Hand Door, Right Hand Door, Rear Window | |
Climate | Heater, Air Conditioning | |
Steering Column | Tilting | |
Steering Controls | Steering Wheel | |
Throttle | Foot Pedal | |
Operator Seat | MF Deluxe ROPS Seat | |
Safety Arrest | 2pt Belt | |
Armrest | Height Adjustable, Pivot | |
Seat | Forward/Reverse Adjustment | |
Suspension | Mechanical | MF Air (AE026) |
Material | Cloth | |
Safety Arrest | 2pt Belt | |
Armrest | Pivot | |
Backrest | Recline | |
Suspension | Air (built in compressor) | |
Rotation | Swivel | |
Windows | Heated Rear | |
Wiper | Front, Rear | |
Sunshade | Windshield | |
Spec Level | Deluxe |
Wheels | ||
---|---|---|
Front | GALXY Agri Trac 9.5-16 | |
Size | 9.5-16 | |
Ply | 6PR | |
Tread Pattern | R1 (Ag) | |
Section Width | 254mm (10") 10" 254mm | |
Overall Diameter | 845.82mm (2' 9-5/16") 2' 9-5/16" 845.82mm | |
Static Loaded Radius | 391.16mm (1' 3-3/8") 1' 3-3/8" 391.16mm | |
Rolling Circumference | 2524.76mm (8' 3-3/8") 8' 3-3/8" 2524.76mm | |
Weight | 19.96kg (44lb.) 44lb. 19.96kg | |
Rear | GALXY Agri Trac 13.6-28 | |
Size | 13.6-28 | |
Ply | 6PR | |
Tread Pattern | R1 (Ag) | |
Section Width | 355.6mm (1' 2") 1' 2" 355.6mm | |
Overall Diameter | 1295.4mm (4' 3") 4' 3" 1295.4mm | |
Static Loaded Radius | 596.9mm (1' 11-1/2") 1' 11-1/2" 596.9mm | |
Weight | 54.43kg (120lb.) 120lb. 54.43kg | |
Front Fenders Width | 1' 13/16" (325mm) 325mm 1' 13/16" |
Dimensions | ||
---|---|---|
Height | 2600.96mm (8' 6-3/8") 8' 6-3/8" 2600.96mm, 2359.66mm (7' 8-7/8") 7' 8-7/8" 2359.66mm | |
Weight | 1830.24kg (4035lb.) 4035lb. 1830.24kg, 2004.88kg (4420lb.) 4420lb. 2004.88kg |
Loader | ||
---|---|---|
Loader | MF FL.2814 | |
Lift Capacity | 852.75kg (1880lb.) 1880lb. 852.75kg | |
Maximum Lift Height – Pivot Pin | 2819.4mm (9' 3") 9' 3" 2819.4mm | |
Lift Capacity to Max Height – Pivot Pin | 1165.73kg (2570lb.) 2570lb. 1165.73kg | |
Breakout Force – Pivot Pin | 1773.54kg (3910lb.) 3910lb. 1773.54kg | |
Max Rollback Angle | 26deg | |
Max Dump Angle | 54deg | |
Lift Cylinder Diameter | 70.1mm (2-3/4") 2-3/4" 70.1mm | |
Bucket Cylinder Diameter | 65.02mm (2-9/16") 2-9/16" 65.02mm | |
3rd Function | Diverter Valve | |
Comfort | Suspension | |
Tool Carrier | Skid Steer Quick Attach | |
Lift Path | Radial |
