23578L | Used 2021 Fendt 516 S4
| Description | |
|---|---|
| 700 hrs, 50kph CVT transmission, Profi Plus, Fendt Guide with Novatel antenna, 158 LPM (42 GPM) hydraulic pump, 4 rear remote valves, Cat 2 front hitch, 1 front remote valve, 650/65R38 and 540/65R28 Trelleborg tires, 300kg/side rear wheel weights, Full halogen lighting package, dual roof-mounted beacons, Super Comfort air seat, Radio, Front axle suspension, mechanical cab suspension, Cargo 4X/80 loader, hydraulic bucket lock, Goldstar warranty until Oct 2024 | |
| Unit Number | 23578L |
| Condition | Used |
| Hours Used | 700 hours |
| Year | 2021 |
| Cost | $246,900.00 CAD |
Specifications
| Engine | ||
|---|---|---|
| Engine Power | 163hp (121kW) | |
| PTO Power | 137hp (102kW) | |
| Rated Engine Speed | 2100r/min | |
| Make | DZ 4.04L Tier 4F 4 Cylinder | |
| Displacement | 4.0L (246.5cu. in.) | |
| Number of Cylinders | 4 | |
| Fuel Type | Diesel | |
| Fuel Injection | Direct Injection | |
| Cooling | Liquid Cooled | |
| Fuel Tank Capacity | 298.0L (78gal.) | |
| DEF Tank Capacity | 31.0L (8gal.) | |
| Warming | Block Heater | |
| Transmission | ||
|---|---|---|
| Maximum Speed | 50km/h (31mph) | |
| Name | CVT ML 90 | |
| Type | Variable | |
| Speed Control | Cruise | |
| Drive | 4WD | |
| Differential | Locking | |
| Additional Drivetrain | ||
|---|---|---|
| Brakes | Wet Disc | |
| Suspension | Front Axle | |
| Hydraulics | ||
|---|---|---|
| Pump | FD 500 S4 42 GPM | |
| Rear Remote Valves | 4 | |
| Front Remote Valves | 1 | |
| Steering | Hydraulic Power Steering | |
| Hitching | ||
|---|---|---|
| Front Hitch | FD 500 S4 | |
| Category | Category 2, Category 3 | |
| Capacity at Pins | 7688lb. (3487kg) | |
| Rear Hitch | FD 500 S4 | |
| Hitch Category | Category 3, Category 2 | |
| Lift Capacity at Pins | 15000lb. (6803kg) | |
| PTO | ||
|---|---|---|
| Rear | 540, 1000 | |
| Type | Independent | |
| Technology | ||
|---|---|---|
| Display | 10.4" Varioterminal | |
| Instrument Display | Digital Dash Display | |
| Entertainment | Bluetooth, Mic, USB | |
| Integration | ISO BUS Implement Control | |
| Antenna | Novatel | |
| Guidance | Guidance Ready | |
| Headland Management | Variotronic TI | |
| Data Transfer | Fendt TaskDoc Pro | |
| Telemetry | 3 Year Fendt Connect Subscription | |
| Electrical | ||
|---|---|---|
| Front Lights | 10 | |
| Rear Lights | 4 | |
| Worklight Type | Halogen | |
| Alternator | 200A | |
| Battery | 1475CCA | |
| Operator Station | ||
|---|---|---|
| Configuration | Cab | |
| Climate | Air Conditioning, Heater | |
| Cab Suspension | 2 Point Mechanical | |
| Steering Column | Tilting, Telescoping | |
| Steering Controls | Steering Wheel | |
| Seat | FD Super Comfort | |
| Material | Cloth | |
| Safety Arrest | 2pt Belt | |
| Armrest | Multi-Function Adjustable | |
| Backrest | Recline | |
| Headrest | Extend | |
| Lumbar Support | Pneumatic | |
| Seat Cushion | Depth Adjustment, Tilt Adjustment | |
| Seat | Forward/Reverse Adjustment | |
| Suspension | Air (built in compressor), Forward/Reverse Horizontal, Low Frequency | |
| Rotation | Segments | |
| Comfort | Heat, Automatic Height Adjustment, Automatic Weight Adjustment | |
| Wiper | 300° Front | |
| Wheels | ||
|---|---|---|
| Front | TRELL 420/85R28 | |
| Size | 420/85R28 | |
| Tread Pattern | R1 (Ag) | |
| Type | Ag | |
| Section Width | 1' 5-3/16" (436mm) | |
| Overall Diameter | 5' 6-1/8" (1678mm) | |
| Static Loaded Radius | 2' 5-7/8" (759mm) | |
| Rolling Circumference | 16' 7-3/16" (5059mm) | |
| Rear | TRELL 520/85R38 | |
| Size | 520/85R38 | |
| Tread Pattern | R1 (Ag) | |
| Type | Ag | |
| Section Width | 1' 9-1/8" (535mm) | |
| Overall Diameter | 6' 13/16" (1849mm) | |
| Static Loaded Radius | 2' 8-1/2" (825mm) | |
| Rolling Circumference | 18' 7/8" (5509mm) | |
| Dimensions | ||
|---|---|---|
| Length | 4453mm (14' 7-5/16") | |
| Wheelbase | 2560mm (8' 4-13/16") | |
| Minimum | 2501mm (8' 2-7/16") | |
| Height | 2965mm (9' 8-3/4") | |
| Weight | 6050kg (13337lb.) | |
| Loader | ||
|---|---|---|
| Loader | FD Cargo 4X/80 | |
| Maximum Lift Height – Pivot Pin | 4155mm (13' 7-9/16") | |
| Digging Depth | 150mm (5-15/16") | |
| Tool Carrier | Euro Quick Attach | |
