Used 2016 Fendt 720 S4

Used Equipment › Used Tractors › Used 2016 Fendt 720 S4
Description
Profi-plus, 50km/hr Vario transmission, front hitch, suspended front axle, 4 rear remotes, 50 GPM hydraulic pump, power beyond, rear hydraulic top link, 300kg wheel weights, LED light package, automatic climate control, super comfort evo-dynamic cloth seat, air cab suspension, pneumatic trailer brake, hydraulic trailer brake, exhaust brake, 600/65R28 fronts, 710/70R38 rears.
Unit Number 23459L
Condition Used
Hours Used 5000 hours
Year 2016
Cost $169,900.00 CAD
Call
Text
Email
Finance
Print
Location

Specifications

Engine
Engine Power 149kW (201hp) 201hp 149kW
PTO Power 123kW (165hp) 165hp 123kW
Rated Engine Speed2100r/min
MakeDZ 6.06L Tier 4F 6 Cylinder
Displacement 369.8cu. in. (6.1L) 6.1L 369.8cu. in.
Number of Cylinders6
Fuel TypeDiesel
Fuel InjectionDirect Injection
CoolingLiquid Cooled
Fuel Tank Capacity 105gal. (400.0L) 400.0L 105gal.
DEF Tank Capacity 10gal. (38.0L) 38.0L 10gal.
WarmingBlock Heater
Transmission
Maximum Speed 31mph (50km/h) 50km/h 31mph
NameCVT ML 180
TypeVariable
Speed ControlCruise
Drive4WD
DifferentialLocking
Additional Drivetrain
BrakesWet Disc
Trailer BrakesAir
SuspensionFront Axle
Hydraulics
PumpFD 700 S4 40 GPM
Hydraulic Flow 151L/min (40.0GPM) 40.0GPM 151L/min
Maximum Operating Pressure 2900psi (200bar) 200bar 2900psi
Rear Remote Valves3
SteeringHydraulic Power Steering
Hitching
Front HitchFD 700 S4
CategoryCategory 2, Category 3
Capacity at Pins 9740lb. (4418kg) 4418kg 9740lb.
Rear HitchFD 700 S4
Hitch CategoryCategory 2, Category 3
Lift Capacity at Pins 19310lb. (8759kg) 8759kg 19310lb.
ComfortDraft Control
PTO
Rear540E, 540, 1000E, 1000
TypeIndependent
Technology
Instrument DisplayDigital Dash Display
EntertainmentBluetooth, Mic, USB
IntegrationISO BUS Implement Control
GuidanceGuidance Ready
Headland ManagementVariotronic TI
Data TransferFendt TaskDoc Pro
Telemetry3 Year Fendt Connect Subscription
Electrical
Front Lights10
Rear Lights4
Worklight TypeHalogen
Alternator200A
Battery1475CCA
Operator Station
ConfigurationCab
ClimateAir Conditioning, Heater
Cab Suspension2 Point Air
Steering ColumnTelescoping, Tilting
Steering ControlsSteering Wheel
SeatFD Comfort
MaterialCloth
Safety Arrest2pt Belt
ArmrestHeight Adjustable
BackrestRecline
HeadrestExtend
Lumbar SupportMechanical
SeatForward/Reverse Adjustment
SuspensionAir (built in compressor), Forward/Reverse Horizontal
Wiper300° Front
Wheels
FrontTRELL 540/65R28
Size540/65R28
Tread PatternR1 (Ag)
TypeAg
Section Width 530mm (1' 8-7/8") 1' 8-7/8" 530mm
Overall Diameter 1412mm (4' 7-5/8") 4' 7-5/8" 1412mm
Static Loaded Radius 637mm (2' 1-1/8") 2' 1-1/8" 637mm
Rolling Circumference 4218mm (13' 10-1/8") 13' 10-1/8" 4218mm
RearTRELL IF650/65R38
SizeIF 650/65R38
Tread PatternTM1000 HP
Section Width 2' 2" (660mm) 660mm 2' 2"
Overall Diameter 6' 7/16" (1840mm) 1840mm 6' 7/16"
Static Loaded Radius 2' 8-11/16" (830mm) 830mm 2' 8-11/16"
Rolling Circumference 18' 15/16" (5510mm) 5510mm 18' 15/16"
Dimensions
Length 17' 2-5/16" (5240mm) 5240mm 17' 2-5/16"
Wheelbase 9' 1-9/16" (2783mm) 2783mm 9' 1-9/16"
Width 8' 4-3/8" (2550mm) 2550mm 8' 4-3/8"
Height 10' 1/16" (3050mm) 3050mm 10' 1/16"
Minimum Ground Clearance 1' 9-5/8" (550mm) 550mm 1' 9-5/8"
Weight 7979kg (17592lb.) 17592lb. 7979kg
Loader
LoaderFD Cargo 5X/85
Bucket Sizes 218cm (7' 2") 7' 2" 218cm, 238cm (7' 10") 7' 10" 238cm, 182cm (6') 6' 182cm, 213cm (7') 7' 213cm
Maximum Lift Height – Pivot Pin 14' 7-9/16" (4460mm) 4460mm 14' 7-9/16"
Lift Capacity to Max Height – Pivot Pin 5844lb. (2651kg) 2651kg 5844lb.
Digging Depth 9-13/16" (250mm) 250mm 9-13/16"
Max Dump Angle55deg
Height ControlPreset Height, Height Limit
3rd FunctionDiverter Valve
Weigh ScaleYes
ComfortHydraulic Bucket Lock, Suspension
Tool CarrierEuro Quick Attach
Self-LevelingHydraulic
Lift PathRadial
