Description
Enclosed cab, heater & air conditioning, 2- speed, joystick with hydro-glide, hi-flow auxiliary, hydraulic quick-tach, 12.00×16.5 tires.
Unit Number 23662H
Condition Used
Hours Used 1260 hours
Year 2022
Cost $54,900.00 CAD

Specifications


Engine
Engine Power 51kW (69hp) 69hp 51kW
Rated Engine Speed2500r/min
MakeYN 4TNV98C
Displacement 201.4cu. in. (3.3L) 3.3L 201.4cu. in.
Number of Cylinders4
Fuel TypeDiesel
Fuel InjectionDirect Injection
CoolingLiquid Cooled
Fuel Tank Capacity 16gal. (62.5L) 62.5L 16gal.

Transmission
Maximum Speed 12mph (20km/h) 20km/h 12mph
TypeHydrostatic
Ranges2

Hydraulics
PumpGH 18.5 GPM
Hydraulic Flow 18.5GPM (70L/min) 70L/min 18.5GPM
Maximum Operating Pressure 20684kPa (3000psi) 3000psi 20684kPa
Maximum Available Hydraulic Oil 8gal. (30.3L) 30.3L 8gal.
Front Remote Valves1

Technology
Instrument DisplayDigital Dash Display

Electrical
Front Lights2
Rear Lights2
Worklight TypeHalogen
Alternator100A
Battery950CCA

Operator Station
ConfigurationCab, Open ROPS
ClimateAir Conditioning, Heater
Steering ControlsJoystick
WiperFront

Wheels
FrontCAMSO SKS 532 10-16.5 NHS
Size10-16.5
Ply10PR
Tread PatternR4 (Ind)
TypeIndustrial
Section Width 276mm (10-7/8") 10-7/8" 276mm
Overall Diameter 767mm (2' 6-3/16") 2' 6-3/16" 767mm
Static Loaded Radius 355mm (1' 2") 1' 2" 355mm
Rolling Circumference 2316mm (7' 7-3/16") 7' 7-3/16" 2316mm
RearCAMSO SKS 532 10-16.5 NHS
Size10-16.5
Ply10PR
Tread PatternR4 (Ind)
TypeIndustrial
Section Width 276mm (10-7/8") 10-7/8" 276mm
Overall Diameter 767mm (2' 6-3/16") 2' 6-3/16" 767mm
Static Loaded Radius 355mm (1' 2") 1' 2" 355mm
Rolling Circumference 2316mm (7' 7-3/16") 7' 7-3/16" 2316mm

Weights
Bolt-OnBumper Counterweight

Dimensions
Length 8' 1/4" (2445mm) 2445mm 8' 1/4"
Wheelbase 3' 6" (1067mm) 1067mm 3' 6"
Width 5' 4-1/2" (1638mm) 1638mm 5' 4-1/2"
Height 6' 8" (2032mm) 2032mm 6' 8"
Minimum Ground Clearance 6-1/2" (165mm) 165mm 6-1/2"

Boom
Maximum Lift Height – Pivot Pin 10' 1/2" (3061mm) 3061mm 10' 1/2"
SAE Tipping Point 3800lb. (1724kg) 1724kg 3800lb.
Max Rollback Angle26deg
Max Dump Angle42deg
ComfortSuspension
Tool CarrierSkid Steer Quick Attach
Lift PathRadial

Components-Loader
Lift Capacity to Max Height – Pivot Pin 2319lb. (1052kg) 1052kg 2319lb.
Breakout Force – Pivot Pin 4049lb. (1837kg) 1837kg 4049lb.
3rd FunctionDiverter Valve
ComfortHydraulic Bucket Lock
