Description | |
---|---|
Profi Plus, Fendt Guide complete- WAAS, 50 km/h Vario transmission, suspended front axle, 58 GPM pump, 5 rear valves, IF750/75R46 rear duals, IF650/65R38 front duals, hydraulic and air trailer brakes, exhaust brake, Evolution seat, LED lights, powered and heated mirrors, air cab suspension, 1000 kg wheel weights, Includes extended warranty and maintenance package. | |
Categories | High Horsepower |
Unit Number | 23270R |
Condition | Used |
Usage | 2200 hours |
Year | 2021 |
Cost | $553,900.00 CAD |
Engine | ||
---|---|---|
Engine Power | 385kW (517hp) 517hp 385kW | |
PTO Power | 372kW (500hp) 500hp 372kW | |
Rated Engine Speed | 1700r/min | |
Make | MAN D2676 LE121 | |
Displacement | 757.9cu. in. (12.4L) 12.4L 757.9cu. in. | |
Number of Cylinders | 6 | |
Fuel Type | Diesel | |
Fuel Injection | Direct Injection | |
Cooling | Liquid Cooled | |
Fuel Tank Capacity | 211gal. (800.0L) 800.0L 211gal. | |
DEF Tank Capacity | 22gal. (85.0L) 85.0L 22gal. | |
Warming | Block Heater |
Transmission | ||
---|---|---|
Maximum Speed | 31mph (50km/h) 50km/h 31mph | |
Name | CVT TA 400 | |
Type | Variable | |
Speed Control | Cruise | |
Drive | 4WD | |
Differential | Locking |
Additional Drivetrain | ||
---|---|---|
Brakes | Dual-Circuit , Wet Disc | |
Trailer Brakes | Hydraulic, Air | |
Suspension | Front Axle | |
Rear Axle Length | 8' 2-7/16" (2500mm) 2500mm 8' 2-7/16" | |
Steering Mode | front wheel steer |
Hydraulics | ||
---|---|---|
Pump | FD 1000 Series Gen3 58.1 GPM | |
Pump Type | Variable Displacement Piston | |
Hydraulic Flow | 58.1GPM (220L/min) 220L/min 58.1GPM | |
System Capacity | 36gal. (139.0L) 139.0L 36gal. | |
Maximum Operating Pressure | 2900psi (20000kPa) 20000kPa 2900psi | |
Maximum Available Hydraulic Oil | 24gal. (93.0L) 93.0L 24gal. | |
Rear Remote Valves | 5 | |
Steering | Hydraulic Power |
Hitching | ||
---|---|---|
Drawbar | Category 4 |
PTO | ||
---|---|---|
Rear | 1000E, 1000 | |
Type | Independent |
Technology | ||
---|---|---|
Display | 10.4" Varioterminal | |
Instrument Display | Digital Dash Display | |
Integration | ISO BUS Implement Control | |
Antenna | Novatel | |
Guidance | Fendt Guide Standard | |
Guidance Precision | WAAS | |
Headland Management | Variotronic TI | |
Auto Headland Turn | Variotronic TI Auto | |
Data Transfer | Fendt TaskDoc Pro | |
Section Control | SectionControl | |
Variable Rate Control | Variable Rate Control | |
Telemetry | 5 Year Fendt Connect Subscription |
Electrical | ||
---|---|---|
Front Lights | 20 | |
Rear Lights | 6 | |
Worklight Type | LED | |
Rotating Beacon | Left, Right | |
Alternator | 160A | |
Battery | 1475CCA | |
Alternator Count | 2 |
Operator Station | ||
---|---|---|
Configuration | Cab | |
Access | Left Hand Door | |
Climate | Air Conditioning, Heater | |
Cab Suspension | 2 Point Air | |
Steering Column | Telescoping, Tilting | |
Steering Controls | Steering Wheel | |
Operator Seat | FD Super Comfort EVO | |
Material | Cloth | |
Safety Arrest | 2pt Belt | |
Armrest | Multi-Function Adjustable | |
Backrest | Adaptive (swivel), Recline | |
Headrest | Extend | |
Lumbar Support | Pneumatic | |
Seat Cushion | Depth Adjustment, Tilt Adjustment | |
Seat | Forward/Reverse Adjustment | |
Suspension | Compressed Air System (no compressor), Dynamic Dampening, Low Frequency, Left/Right Horizontal, Forward/Reverse Horizontal | |
Rotation | Segments | |
Comfort | Automatic Height Adjustment, Heat, Cool, Automatic Weight Adjustment | |
Windows | Heated Rear | |
Wiper | Side, Rear, 300ยฐ Front | |
Mirrors | Heated, Telescoping, Powered | |
Spec Level | ProfiPlus |
Paint | ||
---|---|---|
Wheels | Terra Red | |
Body | Nature Green |
Wheels | ||
---|---|---|
Front | TRELL IF 650/65R38 TM1000 | |
Size | IF 650/65R38 | |
Tread Pattern | TM1000 HP, R1 (Ag) | |
Section Width | 2' 2" (660mm) 660mm 2' 2" | |
Overall Diameter | 6' 7/16" (1840mm) 1840mm 6' 7/16" | |
Static Loaded Radius | 2' 8-11/16" (830mm) 830mm 2' 8-11/16" | |
Rolling Circumference | 18' 15/16" (5510mm) 5510mm 18' 15/16" | |
Tread Thickness | 2-3/8" (60mm) 60mm 2-3/8" | |
Weight | 570lb. (259kg) 259kg 570lb. | |
Rear | TRELL IF 750/75R46 TM1000 | |
Size | 750/75R46 | |
Tread Pattern | TM1000 HP, R1 (Ag) | |
Section Width | 2' 5-1/2" (750mm) 750mm 2' 5-1/2" | |
Overall Diameter | 7' 6-3/4" (2305mm) 2305mm 7' 6-3/4" | |
Static Loaded Radius | 3' 4-9/16" (1030mm) 1030mm 3' 4-9/16" | |
Rolling Circumference | 22' 8-1/4" (6915mm) 6915mm 22' 8-1/4" | |
Tread Thickness | 2-5/8" (67mm) 67mm 2-5/8" | |
Weight | 996lb. (452kg) 452kg 996lb. |
Weights | ||
---|---|---|
Wheel Weights | FD 1000 kg Wheel Weight Pair | |
Mount | Bolt | |
Type | Wheel Disc | |
Weight | 2204lb. (1000kg) 1000kg 2204lb. |
Dimensions | ||
---|---|---|
Length | 20' 10" (6350mm) 6350mm 20' 10" | |
Wheelbase | 10' 9-15/16" (3300mm) 3300mm 10' 9-15/16" | |
Width | 9' 1/4" (2750mm) 2750mm 9' 1/4" | |
Height | 11' 10" (3606mm) 3606mm 11' 10" | |
Minimum Ground Clearance | 1' 11-5/8" (600mm) 600mm 1' 11-5/8" | |
Turning Radius | 24' 9/16" (7330mm) 7330mm 24' 9/16" | |
Weight | 30864lb. (14000kg) 14000kg 30864lb. |
